Standalone Compact Long Distance Automatic Multi Face Detection Capture Facial Recognition Camera AI Smart POE IP WiFi Cam with HTTP WEBSOCKET MQTT Protocol For Your Software Integration
1. 5MP High Resolution
2. Inbuilt POE
3. Motorize lens 6-22mm, optional 6mm/8mm/12mm fixed lens
4. Infrared black&white night vision or color night vision
5. Compact small size
7. Capture upto 32 faces per frame.
8. Firmware customization according to your requirements.
9. Provide HTTP/WEBSOCKET/MQTT protocol and free technical support.
This AI camera works standalone, no need NVR if you do not need to store video in HDD,and it does not come with software, you need to integrate our JSON protocol with your own software or solution, such ass time attendance solution, smart shop management, smart AI security system.
Compact 5MP Multi Face Detection and Face Recognition AI Camera with API JSON protocol
Main Features:
|
1. Offer JSON protocol for your server software integration 2. Built-in deep smart-learning face algorithm, automatically extract face features and self-learn 3. Mini Small size to install easily 4. Support many catpure mode: quick,interval,leave and capture times can be set； 5. Support vertical and horizontal capture angle can be set |
|
6. Support detect Max 32 faces per frame； 7. Support 30*30-700*700 pixel face can be detected； 8. Support upload face photo, human body photo, fullscreen shot, and image quality can be set； 9. Support Digital WDR for HD face exposure； 10. Support 2 Capture mode: backlight mode and normal mode； |
|
Technical Specs |
|
|
|
|
|
MainChip |
Ssc338g， 8GB eMMC |
|
Sensor |
1/2.8" Progressive Scan CMOS IMX335 |
|
Min illumination |
color：0.01Lux@F1.2(AGC ON)，Black&white：0Lux(IR ON) |
|
WDR |
Digital WDR |
|
Fixed Lens |
6mm(default)/8mm/10mm/12mm |
|
Recognition distance |
5-6 meter for 6mm lens, 7-8 meter for 8mm lens, 9-10 meter for 10mm lens, 11-12 meter for 12mm lens |
|
4G/WiFi |
Optional |
|
Main stream resolution |
25fps@（2592×1944，2560× 1440） |
|
Sub stream resolution |
25fps@（704×576） |
|
Encode format |
H.265+/H.265/H.264 |
|
Face Capacity |
50,000 face |
|
Capacity for captured face |
100,000 pcs |
|
Encode bit |
32 Kbps~16 Mbps |
|
H.264 profile |
BaseLine Profile/Main Profile/High Profile |
|
H.265 profile |
Main Profile |
|
Bit Rate control |
· Fixed rate, variable rate ·
|
|
IR Night vision |
18pcs IR led |
|
Enhanced Image |
· Backlight compensation, strong light suppression, 3D digital noise reduction, fog penetration ·
|
|
Image setting |
Rotation, saturation, brightness, contrast, sharpness, AGC, and white balance support for day/night conversion |
|
Network protocol |
HTTP、HTTPS、TCP/IP、UDP、RTP、FTP、RTCP、RTSP、RTMP, WEBRTC,NTP、DHCP、DNS、DDNS、SNMP、SSL/TLS、WebSocket、UPNP、PPPOE,ONVIF |
|
Browser |
Plugin for IE：IE10，IE11 Local preview：Edge，Chrome，Firefox |
|
Waterproof |
IP67 |
|
Camera Dimension |
77*77*56mm |
|
Power input |
DC12V / POE |
