Main Features
◆ Super Starlight HD 3.6mm Lens
◆ Night vision distance: 15-20 meters（IR）
◆Exclusive of IP configuration and IP conflict;
◆ Less latency, better real time effect by lightweight protocol stack
◆H.265(high definition）
◆Conforms to ONVIF2.6 and Private protocol with XMEYE HIKVISION NVR
◆Support mobile phone APP,IE,client , Platform management software surveillance
◆DC12V / POE
|
Hardware |
|||
|
Module |
FH8852 DSP+1/2.9"4MP CMOS GC4053 |
||
|
LUX |
COLOR 0.01[email protected]; B/W 0.001[email protected]; |
||
|
S/N |
≥50db(AGC OFF) |
||
|
WDR |
DWDR; ＞80db |
||
|
Port |
|||
|
Audio Input |
1CH MIC Input |
||
|
Audio Output |
1CH Output, Speaker Optional |
||
|
Light Type |
CDS IR LED/Warm LED/White LED (Support PWM) |
||
|
IO port |
IR CUT, (optional 1CH RESET, Alarm In, Alarm Out) |
||
|
Others |
Extra Motorized Zoom Auto Focus Lens Optional |
||
|
Video Coding |
|||
|
Coding Format |
H.265/H.264 |
||
|
Resolution |
Main Steam |
2560*1440 , 1-30FPS/S |
|
|
2304*1296、1920*1080、1280*720, 1-30FPS/S |
|||
|
Sub steam |
704*576、800*448、640*480、640*360、352*288，1-30FPS/S |
||
|
Video Coding Compression |
128Kbps-8192bps continuous adjustable |
||
|
Subtitle Overlay
|
Support Channel Name, Date & Time, Resolution & 4 lines characters adding |
||
|
Data Transmission &Storage |
|||
|
Data Record |
Video,picture |
||
|
Storage Method |
Cycling Recording, Alarm Recording |
||
|
Alarm Transfer |
IO output, browser, management software |
||
|
Protocol |
ONVIF |
||
|
Mobile |
Support IOS, Android |
||
|
Browser |
Support IE6.0 and above browser(insert Web Server) |
||
|
Mobile Client |
Support iPhone、iPad、Android |
||
|
Temperature |
-30℃ - +60℃ |
||
|
Humidity |
0% - 90% |
||
|
Power |
DC12V /110mA |
||
|
power |
1.3W |
||
